The NetVanta 3200 has the following features:

• Single-slot, single-Ethernet modular IP router
• Feature-rich ADTRAN Operating System (AOS)
• Recognizable Command Line Interface (CLI) and user-friendly, web-based Graphical User Interface (GUI)
• Modular IP access routers for Frame Relay, Multilink Frame Relay, PPP, or Multilink PPP networks
• Standards-based BGP, OSPF, RIP, static routing, and bridging protocols
• Integral stateful inspection firewall protects against Denial of Service (DoS) attempts
• Interchangeable Network Interface Modules (NIMs) with integral DSU/CSU
• 56k/64k DDS, T1/FT1, T1/FT1 + DSX-1, Dual T1, E1/FE1, E1/FE1 + G.703, or ADSL (Annex A or Annex B), SHDSL, and serial NIMs available
• Dial backup to any PPP-compliant device
• Analog modem, ISDN BRI (U or S/T), or serial Dial Backup Interface Modules (DIMs) available
• Auto-sensing 10/100BaseT interface(s)
• Compatible with ADTRAN’s other VPN-equipped NetVanta products
• Quality of Service (QoS) with class-based weighted fair queuing (CBWFQ), low latency queuing (LLQ), weighted fair queuing (WFQ), and DiffServ marking
• Built-in alert and logging mechanisms
• Network Address Translation (NAT/NAPT) and NAT Traversal version 2
• NAT-compatible SIP ALG
• DHCP client, server, and relay
• XAUTH including RADIUS and RSA SecurID
• Flash memory supports dual images of AOS
• TFTP, FTP, XMODEM for firmware upgrades and maintenance updates
• Telnet, HTTP, SSH, SSL, craft/console port, or SNMP management options
• Field-upgradable, remotely configurable interface modules
• Supports up to two T1s of bandwidth
• Self-standing desktop unit with plastic enclosure
• 2.13-inch H x 9-inch W x 6.38-inch D
• Auto-ranging power (90 to 250 VAC, 50/60 Hz)
• Five IPSec VPN tunnels (optional)
